CORE SAND MIXER
Home >> Products >> CORE SAND MIXER
CORE SAND MIXER
| Dome Mixer | 300 Kg. |
| SEW make Geared motor | 22kw /30 HP, 1440 rpm, 3hp 50 Hz. |
| Pan Diameter | 1050 mm |
| Pan Height | 1000 mm |
| No. of blades | 02 with c45 material |
| Total cycle time | 90 sec |
| Motor Pulley | P50 C14m 125 locking element |
| Mixer Pulley | P50 C14m 125 locking element |
| Synchro chain timing belt | 3304 C14m 125 |
| High speed mixer output rpm. | 80 rpm. |
FEATURES
- Bowl Type intensive core sand mixer.
- VFD/PLC Control system for mixing operation.
- High intensive core sand mixing.
- No cleaning of mixer required.
- Less mixing cycle time required.
- Options for automatic, volumetric dosing system for additives.
- Electronic sand weighing system for sand addition.
- Anti-wear coating
